Ship Windows
Fixed and opening configurations, welded, bolted, or clamped, in rectangular, trapezoid, circular, oval, or special shapes.
Ship Windows — Fixed
INSTALLATION METHOD: Welded / Bolted / Clamped
SHAPES AVAILABLE: Rectangular, trapezoid, circular, oval, special
FRAME MATERIAL: Steel (ST), Stainless Steel (SS), Aluminum (AL)
GLASS RETAINER MATERIAL: ST, AL, brass
OPTIONAL MULLION: Vertical, horizontal
OPTIONS: External storm cover, deadlight
Ship Windows — Opening
INSTALLATION METHOD: Welded / Bolted / Clamped
SHAPES AVAILABLE: Rectangular, trapezoid, circular, oval, special
FRAME MATERIAL: Steel (ST), Stainless Steel (SS), Aluminum (AL)
GLASS RETAINER MATERIAL: ST, AL, brass
OPTIONAL MULLION: Vertical, horizontal
OPTIONS: External storm cover, deadlight
Fixed Ship Windows — Fire Rated
A0
A30
A60
Frame: ST, SS Glass Retainer: SS
Opening Ship Windows — Fire Rated
A0
Frame: ST, SS Glass Retainer: SS
Side Scuttles
Round hull portlights in fixed and opening configurations — the classic marine porthole, built to the same standard as our windows.
Side Scuttles — Fixed
INSTALLATION METHOD: Welded / Bolted
FRAME MATERIAL: Steel (ST), Stainless Steel (SS), Aluminum (AL)
GLASS RETAINER MATERIAL: ST, AL, brass
OPTIONAL MULLION: Vertical, horizontal
OPTIONS: External storm cover, deadlight
Side Scuttles — Opening
INSTALLATION METHOD: Welded / Bolted
FRAME MATERIAL: Steel (ST), Stainless Steel (SS), Aluminum (AL)
GLASS RETAINER MATERIAL: ST, AL, brass
OPTIONS: External storm cover, deadlight
Fixed Ship Windows — Fire Rated
A0
A30
A60
Frame: ST, SS Glass Retainer: SS
Opening Ship Windows — Fire Rated
A0
Frame: ST, SS Glass Retainer: SS
Sliding Windows
Horizontal and vertical sliding configurations for bridge and wheelhouse glazing, bolted or welded.
Sliding Windows — Horizontal
INSTALLATION METHOD: Welded / Bolted
SHAPES AVAILABLE: Rectangular, special
FRAME MATERIAL: Steel (ST), Stainless Steel (SS), Aluminum (AL)
GLASS RETAINER MATERIAL: ST, AL, brass
Sliding Windows — Vertical
INSTALLATION METHOD: Welded / Bolted
SHAPES AVAILABLE: Rectangular, special
FRAME MATERIAL: Steel (ST), Stainless Steel (SS), Aluminum (AL)
GLASS RETAINER MATERIAL: ST, AL, brass
.jpeg)
Windshields & Wheelhouses
Center console windshields and custom aluminum pilot houses, crane cabs, and wheelhouses — over 35 years of aluminum fabrication experience for private and commercial fleet vessels.
Center Console Windshields
FRAME MATERIAL: Aluminum, custom powder-coated color
GLASS: ST, AL, brass
CONFIGURATION: Hi-boy, radius, and standard console profiles
OPTIONS: Custom frame + glass color pairing
Pilot Houses, Crane Cabs & Wheelhouses
FABRICATION: Full custom aluminum wheelhouse, pilot house, and crane cab structures
APPLICATION: Private vessels and commercial production fleets
GLAZING: Impact-rated polycarbonate or tempered glass, to spec
EXPERIENCE: 35+ years aluminum wheelhouse fabrication
Ship Doors & Hatches
Weathertight, watertight, and fire-rated doors and hatches — hinged or sliding, single or double leaf. Includes our A-0 and Joiner Door line, engineered for fire, smoke, and toxic gas barrier performance on naval, offshore, and commercial vessels.
ADVM.3201 — Weathertight
Hinged Leaves: 2 Material: ST, SS, AL Bolts: 6, 10
ADVM.3231 — Weathertight
Hinged Leaves: 2 Material: ST, SS, AL Bolts: 9
ADVM.3331 — Weathertight
Hinged Leaves: 1 Material: ST, SS, AL Bolts: 2, 3, 4, 5
ADVM.4245 — Watertight, up to 0.7bar
Hinged Leaves: 2 Material: ST Bolts: 32
ADVM.4445 — Watertight, up to 1.5bar
Hinged Leaves: 1 Material: ST Bolts: 8, 10, 12, 14
ADVM.4545 — Watertight, up to 3.0bar
Hinged Leaves: 1 Material: ST Bolts: 14
TIGHTNESS: Weathertight, Watertight, Internal
FIRE CLASS: A0, A30, A60
MATERIAL: Steel (ST)
BOLTS QTY: 4 to 32, by tightness class
ADVM.5101
Weathertight
A30
Leaves: 1 Bolts: 4
ADVM.5150
A0
Leaves: 1 Bolts: 5
Weathertight
A30
ADVM.5231 / 5232
Weathertight
A60
Leaves: 2 Bolts: 9
ADVM.5231 / 5232
Watertight, up to 0.7bar
A60
Leaves: 2 Bolts: 32
ADVM.5335
Weathertight
A60
Leaves: 1 Bolts: 6,8
ADVM.5340
Weathertight
A60
Leaves: 1 Bolts: 6,8
ADVM.5411 / 5412
Internal
A30
A60
Leaves: 1 Bolts: —
Aluminum Joinery
Hinged and sliding doors, fixed windows, and a modular balcony system in AL 6060 / 6063, anti-corrosion precoat, powder painted.
.jpeg)
.jpeg)
Hinged Doors
Internal, external Non-rated Infill: glass, solid panel
Hinged Doors, Fire Rated
Internal, external
B15
A0
A30
Infill: glass, solid panel
Fixed Window
Internal, external Non-rated,
B15
Infill: glass
Manual Sliding Doors
Internal, external Non-rated Infill: glass, solid panel
Automatic Sliding Doors
Internal, external Non-rated,
A0
Infill: glass, solid panel — heated sill, radar, barrier available
Modular Balcony System
PRESSURE LOAD — DOOR: Up to 19kPa
PRESSURE LOAD — DOOR: Up to 14kPa
MATERIAL: SS, AL 6060/6063
OPTIONS: Child lock, smoke detector, el. drive, AC switch
Wipers
Pantograph, pendulum, and horizontal wiper systems with up to 90% cleaning area coverage.
Pantograph / Pendulum Wipers
MODELS: W40.16-A, W40.16-AS, W60.16-A, W60.16-AS, W60.16-A.02, W60.16-Z
CLEANING AREA: Up to 70%
Horizontal Wipers
MODELS: W40.16-A, W40.16-AS, W60.16-A, W60.16-AS, W60.16-A.02, W60.16-Z
CLEANING AREA: Up to 70%
Accessories: spray system, electrovalves, tanks for spray systems, PSU power distribution cabinets. Control units available in 24VDC and 230VAC, supporting 1–80 wipers per system with ON/OFF, speed regulation, interval regulation, heating control, and spraying control.
Curved Windows
Custom curved windows engineered for any size and configuration
.jpeg)
Have a spec that isn't listed here?
Every product on this page ships custom to your dimensions and fire class. Send your drawing and we'll quote it.
